– 11 –
Component Locator Views
Model JKP85 (Microwave)
Magnatron TCO
High-
Voltage
Capacitor
Fan
Magnatron
Oven Lamp Assembly
Interlock, Monitor,
and Door Sensing
Switches
Power Control Board (PCB)
PC Boards
Connectors
Fuse Fan TCO
Gas
Sensor
Flame
Sensor
Low-Voltage Transformer
High-
Voltage
Diode
High-Voltage
Transformer
Air Duct
