Function
Bake
Broil
Oven Light
Cooking Time
Delay Start Time
Kitchen Timer
Clock
Clear/Off
Pins
11 to 13
10 to 13
11 to 14
12 to 10
11 ro 12
9 to 13
9 to 12
3 to 4
touch pads come as part
.
1 to 2
14 to 9
8 to 14
5to 13
5 to 12
6 to 13
6 to 12
7 to 14
7 to 12
7 to 13
10 to 14
Start
1
2
3
4
5
6
7
8
9
0
Ohmmeter Test
If some of the pads work and some don’t, the
problem is probably the key panel. To verify that
the key panel is the problem, perform the Ohmme-
ter Test. If the ohmmeter reads infinite ohms when
depressing the pad, or shows less than 1 MEG
OHM without depressing the pad, the key panel is
bad. The ohmmeter should read under 200Ω when
pressing a pad.
Set the ohmmeter on the scale that reads approxi-
mately 500Ω. Connect leads to ribbon cable as
indicated in chart for each function. Depress
function pad. Meter should read less than infinity
ohms if the switch contact is working.
Note: Conductors are not all on the same side.
Note: Replacement touch pads come as part of
the control panel.
1 to 2
6 to 13
6 to 14
7 to 13
7 to 14
8 to 13
8 to 14
Start
Up Temp
Dn Temp
Up Hour
Dn Hour
UP Min
Dn Min
NOTE: Replacement touch
pads come as part of the
Control panel.
Function
Bake
Broil
Oven Light
Cooking Time
Delay Start Time
Kitchen Timer
Clock
Clear/Off
Clean
Pins
12 to 14
11 to 14
9 to 13
11 to 13
12 ro 13
10 to 14
10 to 13
3 to 4
9 to 14
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Models JKP27, JKP15, JCKP15, JKS05 and JCKS05
Model JKP45
Model JKP85
FUNCTION
Bake 2 — 14 10 — 14
Broil 2 — 13 10 — 13
Cooking Time 1 — 13 9 — 13
Delay Start Time 1 — 14 9 — 14
Clean 3 — 14 11 — 14
Oven Light 3 — 13 11 — 13
Start 16 — 19 18 — 19
Clear 15 — 19 17 — 19
Temp Up 6-14 8-14
Temp Down 5-14 7-14
UPPER OVEN
CONDUCTOR
CONDUCTOR
COMMON FUNCTIONS
Timer 4 — 13
Clock 4 — 14
Hour Up 6 — 14
Hour Dn 5 — 14
Min Up 8 — 14
Min Dn 7 — 14
LOWER OVEN
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
FUNCTION
Bake 2  14 10  14
Broil 2  13 10  13
Conv. Bake 2  13 10  12
Conv. Roast 1  12 9  12
Cooking Time 1  13 9  13
Delay Start Time 1  14 9  14
Clean 3  14 11  14
Probe 3  12 11  12
Oven Light 3  13 11  13
Start 16  19 18  19
Clear 15  19 17  19
UPPER OVEN
CONDUCTOR
CONDUCTOR
COMMON FUNCTIONS
Timer 4  13 5 6  13
Clock 4  14 6 5  13
1 6  14 7 8  13
2 5  14 8 6  12
3 8  14 9 5  12
4 7  14 0 8  12
LOWER OVEN
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
Models JKP56 and ZEK957
Models JKP18 and JCKP18
FUNCTION
Bake 3 to 4
Broil 1 to 4
Clean 2 to11
Oven Light 1 to 11
Cooking Time 1 to 10
Delay Start Time 3 to 10
Kitchen Timer 1 to 9
Clock 3 to 9
Clear/Off 13 to 14
Start 12 to 14
Conv. Bake 2 to 4
PINS
NOTE: Conductors are on either
side but not both, Pin numbers are
shown on control.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
FUNCTION
Conv. Roast 2 to 10
Probe 3 to 11
1 3 to 6
2 3 to 5
3 3 to 8
4 3 to 7
5 1 to 6
6 1 to 5
7 1 to 8
8 2 to 6
9 2 to 5
FUNCTION
0 2 to 8
Proof 2 to 7
PINS
PINS
