– 13 –
Model JKP45 (Double Oven)
Keyboard
Ribbon
Connector
J 5
(L1 + N)
Lower Lock Mtr
Oven Sensor
Oven Sensor
Door Jam SW
BR2
Upper Lock Mtr
BA1
BR1
BA2
J6
J4
(Upper Oven Temp
Sensor, LKSW1,
and LKSW2)
J3
(Lower Oven Temp
Sensor, Therm SW,
LKSW1, and
LKSW2)
Door Lock Therm SW,
Motorized Door Lock,
Fan Therm SW
Oven Light
