Gecko in.ye-3 User Manual

5
Overview
in.ye dimensions
Main power
entry connection
heat�wav heater
Watertight strain
relief system
Mounting feet
Industry-standard AMP
connectors for outputs
Enough outputs for all
your spa needs
Light output (12 V DC)
Main keypad connector
Communications link
Accessible
bonding lugs
Front view
Side view
4�98"
(126 mm)
2"
(51 mm)
10�75"
(273 mm)
16�55"
(420 mm)
19�60"
(498 mm)
2�88 "
(73 mm)
10�47"
(266 mm)
1�63"
(41 mm)
2�61"
(66 mm)
Bottom view
4�56"
(115 mm)
2�25"
(57 mm)
4�29"
(108 mm)
7�16"
(182 mm)
Rear view
17"
(431 mm)
Note: Shown with optional wall mouting brackets (see Installation)�
Access to heater
connections
2�38 "
(60�3 mm)
in.ye overview
RS-485
communication link

Gecko in.ye-3 Specifications

General

Brand	Gecko
Model	in.ye-3
Category	Spa Accessories
Language	English
