Gecko in.ye-3 User Manual

17
Output cable
Strain relief bracket
1/8" (3 mm) max
Replace the cover� Do not over tighten cover screws
(torque to 8 in� lb max (0�9 N�m)
The cable jacket must not exceed the strain relief bracket
more than 1/8" (3 mm)�
Connections
Once all cables of high voltage accessories are routed
through the openings provided for this purpose on each
sides of the enclosure of the control system, you can
replace the strain relief brackets�
Completing the installation
in.yt
in.ye
For 14-4
cable size
(∅ 0�410"
to 0�425")
For 14-3/18-3
cable size
(∅ 0�305"
to 0�375")
For 14-3/18-3
cable size
(∅ 0�305"
to 0�375")
For 14-3/18-3
cable size
(∅ 0�305"
to 0�375")
For 14-4/14-3
cable size
(∅ 0�365"
to 0�425")
For 14-4/14-3
cable size
(∅ 0�365"
to 0�425")
For 14-4/14-3
cable size
(∅ 0�365"
to 0�425")
For 14-4 only
cable size
(∅ 0�410"
to 0�425")
Output cable opening size
