in.yt overview
Main power
entry connection
heat�wav heater
Watertight strain
relief system
Access to heater
connections
Mounting feet
Communications link
Enough outputs for all
your spa needs
Main keypad connector
Communications link
Accessible
bonding lugs
Front view
Side view
5�16"
(130 mm)
2"
(51 mm)
14�5"
(368 mm)
Bottom view
16�62"
(422 mm)
19�60"
(498 mm)
2�88"
(73 mm)
10�47"
(266 mm)
1�63"
(41 mm)
2�61"
(66 mm)
11�0"
(279 mm)
4�29"
(109 mm)
Note: Shown with optional wall mounting brackets (see Installation)�
2�04"
(52 mm)
8�09"
(205 mm)
10�96"
(278 mm)
Rear view
16�90"
(429 mm)
2�38 "
(60�3 mm)
Overview
in.yt dimensions
Industry-standard AMP
connectors for outputs
Light output (12 V DC)
RS-485
communication link
