gefran 600 User Manual

al.n
bvt.
+ 8 to enable HB alarm
+ 16 to enable LBA alarm
dig.
Function
of digital input
+ 16 for input in denied logic (NPN)
+ 32 to force logic state 0 (OFF)
+ 48 to force logic state 1 (ON)
AL.nr Alarm 1 Alarm 2 Alarm 3
0 disabled disabled disabled
1 enabled disabled disabled
2 disabled enabled disabled
3 enabled enabled disabled
4 disabled disabled enabled
5 enabled disabled enabled
6 disabled enabled enabled
7 enabled enabled enabled
0 No function (key disenabled)
1 MAN / AUTO controller
2 LOC / REM
3 HOLD
4 Alarms memory reset
5 SP1/SP2 Selection
6 Software on/off
7 F key block
Select number of
enabled alarms
0 No function (key disenabled)
1 MAN / AUTO controller
2 LOC / REM
3 HOLD
4 Alarms memory reset
5 SP1 / SP2 Selection
6 Start / Stop selftuning
7 Start / Stop autotuning
8 Set / Reset outputs Out 1... Out 4
+ 16 disables the “back menu” function
(Auto/Man + F keys) in the configuration
menus
b u t t
Function of M/A
keys
dig.
ld.1
ld.2
ld.3
Function of LEDs
dsp
Defining SV
display function
diSP Lower display (SV) function
0 SSP - setpoint enabled
1 InP.2 - aux input
2 Control output value
3 Deviation (SSP - PV)
Val. Function
0 none
1 MAN/AUTO controller
2 LOC / REM
3 HOLD
4 Selftuning enabled
5 Autotuning enabled
6 IN1 repetition
7 Enable serial dialogue
8 Error present
9 Softstart running
10 SP1...SP2 Indication
11 Set point gradient running
+ 16 LED flashes if active
10 80336L_MHW_600_07-2011_ENG
10 / 31

gefran 600 Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Output Type	Relay, SSR, Voltage, Current
Power Supply	24V AC/DC, 100-240V AC
Dimensions	48x96mm, 96x96mm
Communication	RS485
Operating Temperature	0...+50 °C / 32...+122 °F
Storage Temperature	-20...+70 °C / -4...+158 °F
Control Type	PID Controller
