gefran 600 User Manual

5 • “EASY” PROGRAMMING and CONFIGURATION
al.1
P.V. / S.V.
P.V. / S.V.
Process variable (PV display)
Work Setpoint (SV display) or control
output value with controller in manual
Alarm point 1 (scale points)
LEVEL 1 MENU
• CFG
• InP
h.pb
h.it
h.dt
h.p.x
Xy.i
Proportional band
for heating or hysteresis
in regulation ON/OFF
Integral time
for heating
Derivative time
for heating
Maximum power limit
for heating
0 ... 999.9%
full scale
0.00 ... 99.99 min
0.00 ... 99.99 min
0.0 ... 100.0%
Alarm 1 hysteresis
0...999 sec.
If +32 in A1.t
0...999 min.
If +64 in A1.t
±999 scale points
typ.
Probe type, signal, enable custom linearization, and main input
scale (See type table, page 6)
dp.s
lo.s
Decimal point position for
main input scale
Minimum limit of main
input scale
Maximum limit of main
input scale
dP_S Format
0 xxxx
1 xxx.x
2 xx.xx
3 x.xxx
min...max input range
selected in tyP
min...max input range
selected in tyP
xi.s
• Out
• Prot
xi.l
lo.l
Lower limit for local
setpoint and absolute
alarms
Lo.S ... Hi.S
Upper limit for local
setpoint and absolute
alarms
Lo.S ... Hi.S
Alarm
type 1
AL.x.t Direct (high limit) Absolute Normal
Inverse (low limit) or relative Symmetrical
to active setpoint (window)
0 direct absolute normal
1 inverse absolute normal
2 direct relative normal
3 inverse relative normal
4 direct absolute symmetrical
5 inverse absolute symmetrical
6 direct relative symmetrical
7 inverse relative symmetrical
AL.1.t, AL.2.t, AL.3.t
a1.t
(t.2
Cycle time for
Out2
(Heat or Cool)
1...200 sec.
Pro
Protection code
Prot Display Modification
0 SP, alarms SP, alarms
1 SP, alarms SP
2 SP
+ 4 to disable InP, Out
+ 8 to disable CFG
+128 enables full configuration
THE EASY CONFIGURATION IS SUITABLE FOR VERSIONS
WITH TWO OUTPUTS (OUT1, OUT2). TO ACCESS THE OTHER
PARAMETERS, ADD 128 TO THE Pro VALUE.
+ 8 to disable at power-on until first alarm
+ 16 to enable alarm memory
+ 32 Hys becomes delay time when alarm trips (0...999 sec.)
(excluding symmetrical absolute)
+ 64 Hys becomes delay time when alarm trips (0...999 min.)
(excluding symmetrical absolute)
InP
Out
PAS = 99
Pro
Input settings
Output settings
PAS
Custom menu
Password
Protection code
CFG
S4 Jumper
(CPU)
ON
Nelle scale tempi 0-999sec/0-
999min non ha significato la
presenza del punto decimale
(per dP.S diverso da 0)
380336L_MHW_600_07-2011_ENG
3 / 31

gefran 600 Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Output Type	Relay, SSR, Voltage, Current
Power Supply	24V AC/DC, 100-240V AC
Dimensions	48x96mm, 96x96mm
Communication	RS485
Operating Temperature	0...+50 °C / 32...+122 °F
Storage Temperature	-20...+70 °C / -4...+158 °F
Control Type	PID Controller
