gefran 600 User Manual

Step 34 mV full scale
s.34
Step 33
mV beginning scale
s.33
......
s.00
• Lin
Lin
Custom linearization for main input
the n step value corresponds to input:
mV beginning scale + n*∆mV
∆mV = (mV full scale - mV beginning scale) / 32
Step 0 beginning
of scale value
Step 32
full of scale value
Display limits
(-1999…9999)
Display limits
(-1999…9999)
• U.CAL
U.CA
User
calibration
s.32
Step 35
mV at 50°C
s.35
Val Function
1 Analogue output (1)
2 Input 1 – custom 10V / 20mA
3 Input 1 - custom 60mV
4 Custom PT100 / J PT100
5 Custom PTC
6 Custom NTC
7 Input 2 - custom TA (2)
Only for TYP = Tc custom
(1) The analog output in 20mA is calibrated with accuracy higher than 0.2 % f.s.; calibrate when
converting to 10V output.
(2) In the absence of calibration, accuracy is higher than 1% f.s.; calibrate only if higher
accuracy is required.
1180336L_MHW_600_07-2011_ENG
11 / 31

gefran 600 Specifications

General

Input Type	Thermocouple, RTD, Voltage, Current
Output Type	Relay, SSR, Voltage, Current
Power Supply	24V AC/DC, 100-240V AC
Dimensions	48x96mm, 96x96mm
Communication	RS485
Operating Temperature	0...+50 °C / 32...+122 °F
Storage Temperature	-20...+70 °C / -4...+158 °F
Control Type	PID Controller
