ADL300-EPCv2- User Guide Page 22 of 64
4. COMMISSIONING VIA KEYPAD
4.1 ASYNCHRONOUS MOTOR START-UP WIZARD
From ADL300 quick start guide page 48/80 for asynchronous motor and page 55/80 for brushless
motor
The STARTUP WIZARD is a guided procedure used for quick start-up of the drive that helps to set the main
parameters.
It consists of a series of questions, relating to the various sequences for entering and calculating the
parameters necessary for correct drive and lift application operation. The order of these sequences is as
follows:
● Electrical connections See step 1
(see QS manual)
● Setting motor parameters See step 2
(see QS manual)
● Autotune with motor at stand-still or coupled to the load See step 3
(see QS manual)
● Setting encoder parameters See step 4
(see QS manual)
● Setting the maximum speed reference and maximum system speed
See step 6
(see QS manual)
● Setting system weights See step 7
(see QS manual)
● Setting application parameters See step 8
● Saving parameters See step 9
4.2 SYNCHRONOUS MOTOR START-UP WIZARD
● Electrical connections See step 1 (see QS manual)
● Setting motor parameters See step 2
(see QS manual)
● Autotune with motor at stand-still or coupled to the load See step 3
(see QS manual)
● Setting encoder parameters See step 4
(see QS manual)
● Encoder phasing See step 5
(see QS manual)
● Setting the maximum speed reference and maximum system speed
See step 6
(see QS manual)
● Setting system weights See step 7
(see QS manual)
● Setting application parameters See step 8
● Saving parameters See step 9
