ADL300-EPCv2- User Guide Page 57 of 64
The set of lift output signals is comprised in two LiftStatusWords. A selector enables the two status words to
be connected to Pad 11 or 12 or to fieldbus S ->M1 or S -> M2.
6.7 Status Word Composition
The set of lift output signals has been composed in two LiftStatusWords, connected respectively to Pad 11
and Pad 12. Possible selections also include the process channels of fieldbus S ->M1 or S -> M2.
Lift Status word 1:
Bit
Description
Remarks
0
LiftEnable
Lift enable command.
1
RunCont
Run command contactor
2
UpCont
Up command contactor
3
DownCont
Down command contactor
4
BrakeCont
Brake command contactor
5
LiftDcBrake
DC brake function command (firmware)
6
Brake2
Brake control signal (See sequences)
7
DoorOpen
Open door command
8
Drive OK
Indicates drive not in alarm condition
9
SpeedIsZero
Indicates speed below the 0 threshold
10
SpeedRefIsZero
Indicates speed reference below the 0 threshold
11
12
13
14
15
Lift Status word 2:
Bit
Description
Remarks
0
Floor Command
Floor call command being executed
1
SelfStudyOn
Self study command being executed
2
SelfStudyOk
Self study command OK
3
StartCycle0
Zero cycle command being executed
4
ZeroFound
Zero cycle command OK
5
PosReady
Positioning device ready
6
Battery Sel
Battery fwd
7
Battery Run
Battery rev
8
RESERVED
Reserved for next stop
9
RESERVED
Reserved for battery mode run
10
AtFloor
Lift at floor
11
PassingBP1
Passing Brake Point
12
PassingBP2
Passing Brake Point
13
UpContMon
14
DownContMon
15
DoorOpenMon
