Table 4.2 Analog input property list (READ)
No.
Object
Name
Description Unit Classification Range
AI0
TM2 AVI
AVI input
Percent
R
0 - 100
AI1
TM2 ACI
ACI input
Percent
R
0 - 100
AI2
Error code
Recent fault message
No Units
R
0 –43
AI3
Freq cmd
Frequency command
HZ
R
0 - 599
AI4
Frequency
Output frequency
HZ
R
0 -599
AI5
Current
Output current
Amps
R
AI6
Control
Mode
Control mode No Units R
0 - 1
AI7
Motor R-Volt
Motor rated voltage
Volt
R
AI8
Motor R-HP
Motor rated power
horsepower
R
AI9 Motor
R-RPM
Motor rated rotation
speed
rpm R
AI10
Motor R-Hz
Motor rated frequency
HZ
R
AI11
CarrierFreq
Carrier frequency
KiloHertz
R
1 - 16
AI12 Comm
Station
INV communication
station
No Units R 1 – 32
AI13
BaudRate
Baudrate setting
No Units
R
0 – 3
AI14 BacnetSel Communication mode
selection
No Units R 0 – 2
AI15
DevInstance
Inverter number
No Units
R
1 - 254
Table 4.3 – Analog output property list (READ/ WRITE)
No. Object Name Description Unit
Classificat
ion
Range
AO0
Set Frequency
Frequency command
HZ
R/W
0 - 599
AO1
AO
Output voltage
Volt
R
0 - 10
AO3
Motor R-Amp
Motor rated current
Amps
R/W
0-65535
AO4 PwrL Sel
Momentary stop and
restart selection
No Units R 0 - 1
AO5 RestartSel
Number of Fault
Auto-Restart Attempts
No Units R 0 – 10
AO6 RestartDelay
Fault Auto-Restart
Time
seconds R 0 - 800
AO7 FreqCommand1
Speed frequency
setting-stage 0
HZ R/W 0 - 599
