Error 6 verification time
0 ~ 20
3
09-09
Drive Transmit
delay Time
（
ms
）
5 ~ 65
5 2ms
09-10
BACnet stations
1~254
1
Group10- PID function Setup
No. Description Range
Factory
Setting
Unit Note
10-00
PID target value selection
(when 00-05\00-06=6,
this function is enabled)
0:Potentiometer on Keypad
1: Analog Signal Input. (AVI)
2: Analog Signal Input. (ACI)
3: Frequency set by communication
4: Keypad Frequency parameter 10-02
5: Preset frequency
1 - *1
10-01
PID feedback value
selection
0: Potentiometer on Keypad
1: Analog Signal Input. (AVI)
2: Analog Signal Input. (ACI)
3: Communication Setting Frequency
2 - *1
10-02
PID Target (keypad input)
0.0~100.0
50.0
%
*1
10-03
PID Mode Selection
0:Disabled
1: Deviation D Control.
FWD Characteristic.
2: Feedback D Control
FWD Characteristic.
3: Deviation D Control
Reverse Characteristic.
4: Feedback D Control
Reverse Characteristic.
5: Frequency Command + Deviation D Control.
FWD Characteristic.
6: Frequency Command + Feedback D Control
FWD Characteristic.
7: Frequency Command + Deviation D Control
Reverse Characteristic.
8: Frequency Command + Feedback D Control
Reverse Characteristic.
0 -
10-04
Feedback Gain
Coefficient
0.00 ~ 10.00 1.00 % *1
10-05
Proportional Gain
0.0 ~ 10.0
1.0
%
*1
10-06
Integral Time
0.0 ~ 100.0
10.0
s
*1
10-07
Derivative Time
0.00 ~ 10.00
0.00
s
*1
10-08
PID Offset
0: Positive
1: Negative
0 - *1
10-09
PID Offset Adjust
0 ~ 109
0
%
*1
10-10
PID Output Lag Filter
Time
0.0 ~ 2.5 0.0 s *1
10-11
Feedback Loss Detection
Mode
0: Disabled
1: Enabled - Drive Continues to Operate After
Feedback Loss
2: Enabled - Drive "STOPS"
After Feedback Loss
0 -
10-12
Feedback Loss Detection
Level
0 ~ 100
0 %
10-13
Feedback Loss Detection
Delay Time
0.0 ~25.5
1.0 s
10-14
Integration Limit Value
0 ~ 109
100
%
*1
