gefran BDI50 Series

4-36
03- External digital inputs & Relay Output functions
03- 00
Multifunction Input Term. S1
03- 01
Multifunction Input Term. S2
03- 02
Multifunction Input Term. S3
03- 03
Multifunction Input Term. S4
03- 04
Multifunction Input Term. S5
Range
【
0
】
:Forward/Stop Command-------------------(Parameters 00- 02/00-03=1 & 00-04)
【
1
】
:Reverse/Stop Command---------------------(Parameters 00-02/00-03=1 & 00-04)
【
2
】
:Preset Speed 1 (5- 02)--------------------- (Parameter Group5)
【
3
】
:Preset Speed 2 (5- 03)----------------------(Parameter Group5)
【
4
】
:Preset Speed 4 (5- 05) ---------------------(Parameter Group5)
【
6
】
:JOG Forward Command-------------------(Parameters 00-18~00-20)
【
7
】
:JOG Reverse Command------------------ (Parameters 00-18~00-20)
【
8
】
:Up Command--------------------------- (Parameters 00- 05/00- 06=4& 03-06/03-07)
【
9
】
:Down Command----------------------- (Parameters 00- 05/00- 06=4& 03-06/03-07)
【
10
】
: 2
nd
Acc/Dec times
【
11
】
: Disable Acc/Dec
【
12
】
: Main/ Alternative run source Select-----------------(Parameters 00- 02/00- 03)
【
13
】
: Main/Alternative Frequency Command Select----(Parameters 00- 05/00- 06)
【
14
】
: Rapid Stop (controlled deceleration stop)
【
15
】
: Base Block (Coast to stop)
【
16
】
: Disable PID Function.----------------------------------(Parameter Goup10)
【
17
】
: Reset
【
18
】
: Enable Auto Run Mode--------------------------------(Parameter Group 6)
Various example settings and descriptions for Parameters 03-00 to 03-04 are noted in the
following pages seconds from 1 to 13.
