gefran BDI50 Series - Page 92

4-45
03-16
Fixed
Value
100msec
03-
15
03
-11
ON
I load
100
%
T
03-17
Brake Release Level
Range
【
0.00~20.00
】
Hz
03-18
Brake Engage Level
Range
【
0.00~20.00
】
Hz
 If 03-11 =
【
14
】
 In accelerating mode. RY1 will be ON as soon as the actual output frequency reaches the
external Brake release level set in parameter 03-17.
 In decelerating mode, RY1 will be OFF as soon as the actual output frequency reaches the
external Brake engage level set in parameter 03-18.
Timing diagram for 03-17 < 03-18 is shown below:
03-17
03-18
03-11=14
RUN command
Hz
T
ON OFF
RUN STOP
Timing diagram for 03-17 > 03-18 is shown below:
