6580397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
AUXILIARY ANALOG INPUT (LIN/TC)
194
AI.2
R/W
Select type of auxiliary input sensor
181
tp.2
R/W
Definition of auxiliary analog input
function
677
dP.2
R/W
Decimal point position for auxiliary input
scale
404
LS.2
R/W
Minimum limit auxiliary input scale
603
XS.2
R/W
Maximum limit auxiliary input scale
605
oFS.2
R/W
Offset correction for auxiliary input
604
FLt.2
R/W
Digital filter for auxiliary input
602
In.2
R
Value of auxiliary input
606
Er.2
R
Self-diagnosis error code of auxiliary
input
DIGITAL INPUTS
140
diG.
R/W
Function of digital input
618
diG.2
R/W
Function of digital input 2
68
bit
STATE OF DIGITAL
INPUT 1
OFF = Digital input 1 off
ON = Digital input 1 on
R
92
bit
STATE OF DIGITAL
INPUT 2
OFF = Digital input 2 off
ON = Digital input 2 on
R
317
R
State of digital inputs INPUT DIG
