gefran GFXTERMO4 User Manual

66
880397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
GENERIC ALARMS AL1, AL2, AL3 e AL4
215
a1.r
R/W
Select reference variable alarm 1
216
A2.r
R/W
Select reference variable alarm 2
217
A3.r
R/W
Select reference variable alarm 3
218
A4.r
R/W
Select reference variable alarm 4
12
475 - 177
AL.1
R/W
Setpoint alarm 1 (scale points)
13
476 - 178
AL.2
R/W
Setpoint alarm 2 (scale points)
14
52 - 479
AL.3
R/W
Setpoint alarm 3 (scale points)
58
480
AL.4
R/W
Setpoint alarm 4 (scale points)
27
187
XY.1
R/W
Hysteresis for alarm 1
30
188
XY.2
R/W
Hysteresis for alarm 2
53
189
XY.3
R/W
Hysteresis for alarm 3
59
XY.4
R/W
Hysteresis for alarm 4
406
a1.t
R/W
Alarm type 1
407
A2.t
R/W
Alarm type 2
408
54
A3.t
R/W
Alarm type 3
409
A4.t
R/W
Alarm type 4
25
20 - 28 - 142
Lo.L
R/W
Lowest settable limit SP, SP
remote and absolute alarms
46
bit
AL1 direct/inverse R/W
47
bit
AL1 absolute/relative R/W
48
bit
AL1 normal/symmetrical R/W
49
bit
AL1 disabled at switch on R/W
50
bit
AL1 with memory R/W
54
bit
AL2 direct/inverse R/W
55
bit
AL2 absolute/relative R/W
56
bit
AL2 normal/symmetrical R/W
57
bit
AL2 disabled at switch on R/W
58
bit
AL2 with memory R/W
36
bit
AL3 direct/inverse R/W
37
bit
AL3 absolute/relative R/W
38
bit
AL3 normal/symmetrical R/W
39
bit
AL3 disabled at switch on R/W
40
bit
AL3 with memory R/W
