gefran GFXTERMO4 User Manual

6780397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
26
21 - 29 - 143
xI.L
R/W
Highest settable limit SP, SP
remote and absolute alarms
195
AL.n
R/W
Select number of enabled alarms
140
diG.
R/W
Digital input function
618
diG.2
R/W
Digital input function 2
70
bit
AL4 direct/inverse R/W
71
bit
AL4 absolute/relative R/W
72
bit
AL4 normal/symmetrical R/W
73
bit
AL4 disabled at switch on R/W
74
bit
AL4 with memory R/W
4
bit
STATE OF
ALARM 1
OFF = Alarm off
ON = Alarm on
R
5
bit
STATE OF
ALARM 2
OFF = Alarm off
ON = Alarm on
R
62
bit
STATE OF
ALARM 3
OFF = Alarm off
ON = Alarm on
R
69
bit
STATE OF
ALARM 4
OFF = Alarm off
ON = Alarm on
R
318
R
States of alarm ALSTATE IRQ
79
bit
Reset alarm latch R/W
LBA ALARM (Loop Break Alarm)
195
AL.n
R/W
Select number of enabled alarms
44
Lb.t
R/W
Delay time for LBA alarm activation
119
Lb.p
R/W
Limit of supplied power in presence of
LBA alarm
8
bit
STATE OF LBA ALARM
OFF = LBA off
ON = LBA alarm on
R
81
bit
Reset LBA alarm R/W
HB ALARM (Heater Break Alarm)
57
Xb.f
R/W
HB alarm function
195
AL.n
R/W
Select number of enabled alarms
55
A.xb1
R/W
HB alarm setpoint (ammeter input scale
points - Phase 1)
56
XB.T
R/W
Delay time for HB alarm activation
502
A.xb2
R/W
HB alarm setpoint (ammeter input scale
points - Phase 2)
503
A.xb3
R/W
HB alarm setpoint (ammeter input scale
points - Phase 3)
26
bit
STATE OF HB ALARM or
POWER_FAULT
OFF = Alarm off
ON = Alarm on
R
76
bit
State of HB alarm
phase 1TA
R
77
bit
State of HB alarm
phase 2TA
R
78
bit
State of HB alarm
phase 3TA
R
512
R
States of alarm ALSTATE
(for single-phase loads)
504
R
States of alarm HB ALSTATE_HB
(for 3-phase loads)
