gefran GFXTERMO4 User Manual

68
880397M_MSW_GFX4-GFXTERMO4_08-2018_ENG
ALARM SBR - ERR (Probe in short or connection error)
229
rEL
R/W
Fault action (in case of broken probe)
Sbr, Err Only for main input
228
fa.p
R/W
Fault action power
(supplied in condition of broken probe)
Power Fault ALARMS (SSR SHORT, NO_VOLTAGE, SSR, OPEN and NO_CURRENT)
660
hd.2
R/W
Enable POWER_FAULT alarms
661
dg.t
R/W
Refresh rate ln.TA
- (only for GFX4 1TA)
662
dg.f
R/W
Filter in time for NO_VOLTAGE,
SSR_OPEN and NO_CURRENT alarms
(GFX4-1TA excluded)
663
dg.p
R/W
Min. acquisition power In.TA and for
NO_CURRENT (only for GFX4 1TA)
9
bit
STATE OF INPUT IN SBR
OFF = -
ON = Input in SBR
R
85
Err
R Self-diagnosis error code for main input
93
bit
State of alarm
SSR_OPEN phase 1
R
94
bit
State of alarm
SSR_OPEN phase 2
R
95
bit
State of alarm
SSR_OPEN phase 3
R
96
bit
State of alarm
SSR_SHORT phase 1
R
97
bit
State of alarm
SSR_SHORT phasee 2
R
98
bit
State of alarm
SSR_SHORT phase 3
R
99
bit
State of alarm
NO_VOLTAGE phase 1
R
100
bit
State of alarm
NO_VOLTAGE phase 2
R
101
bit
State of alarm
NO_VOLTAGE phase 3
R
102
bit
State of alarm
NO_CURRENT phase 1
R
103
bit
State of alarm
NO_CURRENT phase 2
R
104
bit
State of alarm
NO_CURRENT phase 3
R
105
bit
Reset SSR_OPEN /SSR_
SHORT / NO_VOLTAGE /
NO_CURRENT alarms
R/W
655
R
INPTC
ALARM due to overload
675
R
INPTC_DER
