gefran GTF - Enabling and Setting Feedback Modes; Feedback Reference Value Settings

26
80961F_MSW_GTF/GTF-Xtra_07-2018_ENG
0.0 ...999,9 V
47
Rif.v
R/W
Voltage feedback reference
0,0
0.0 ...999,9 A
48
Rif.A
R/W
Current feedback reference
0,0
0.0 ...150,00 kW
0 ...1
49
Rif.p
R/W
Power feedback reference
0,0
0
15
bit
Calibration of voltage
feedback reference
R/W
OFF = Calibration not enabled
ON = Calibration enabled
46
xd.6
R/W Enable feedback modes
0
Table of feedback modes
Read state
0 None
1 V
2
(Voltage)
2 I
2
(Current)
3 P (Power)
4 None
5 V (Linear voltage)
6 I (Linear current)
0.0 ...999,9 A
0.0 ...999,9 A
0.0 ...150,00 kW
108
Feedback
reference
R
Setpoint V, I, P to be maintained on load
Note:
Values of V (I) are expressed in tenths of Volt
(Amperes)
Values of P are expressed in tenths of Watt)
0.1 ...1,0
% / 60msec
157
Fb.It
R/W
Feedback Response Speed
0,3
