PARAMETERS
INSTRUMENT CONFIGURATION SHEET
Denition of parameter Note
Assigned
value
MAIN INPUT
29
Lo.S
R/W
Minimum scale limit of main input
27
tYP.
R/W
analog input
30
xi.S
R/W
Maximum scale limit of main input
31
ofs.
R/W
Offset correction for main input
0
P. V.
R
Read of engineering value of
process variable (PV)
28
flt
R/W
Low pass digital filter
on input signal
INSTALLATION OF MODBUS SERIAL NETWORK
25
par
R/W
Select parity
24
baV
R/W Select Baudrate
23
(od
R
Identification code
LOAD CURRENT VALUE
33
L.tA
R Minimum scale limit of CT input
34
x.ta
R Maximum scale limit of CT input
35
o.tA
R/W Offset correction CT input
94
I.taP
R
Peak ammeter input during phase
softstart ramp
88
I.onf
R
CT filtered ammeter input value with
output activate
87
I.ta
R Offset correction CT input
104
ld.a
R
Current on load
32
FT.A
R/W CT input digital filter
163
(.E.t
R/W
Timeout due to communication failure
164
(.E.P
R/W
Output power when communication
failure is active
