VALUE OF LOAD VOLTAGE
37
L.t
R Minimum scale limit of TV input
38
x.t
R Maximum scale limit of TV input
103
frE
q
R
Voltage frequency in tenths of Hz
97
I.t f
R
Voltmeter input value
96
I.t
R
Voltmeter input value
105
Ld.
R Voltage on load
39
o.t
R/W
Offset correction voltmeter
transformer input TV
36
FT.
R/W
Digital filter TV auxiliary input
LINE VOLTAGE VALUE
POWER ON LOAD
106
Ld.P
R
Power on load
107
Ld.I
R
Impedance on load
DIGITAL INPUTS
5
bit
STATE OF DIGITAL
INPUT
OFF = Digital input off
ON = Digital input on
R
54
diG.
R/W
Function of digital input
118
R
State of digital inputs INPUT DIG
83
R/W
Timeout per ingresso PWM
P
.T
