3380961F_MSW_GTF/GTF-Xtra_07-2018_ENG
72
Ir.t .0
R/W
73
Ir.t .1
R/W
74
Ir.t .2
R/W
75
Ir.t .3
R/W
TV read in HB calibration to 30%
with conduction (only for IR lamps)
TV read in HB calibration to 20%
with conduction (only for IR lamps)
TV read in HB calibration to 50%
with conduction (only for IR lamps)
TV read in HB calibration to100%
with conduction (only for IR lamps)
76
Ir.t .4
R/W
TV read in HB calibration
to 15% with conduction
(only for IR lamps)
77
Ir.t .5
R/W
TV read in HB calibration
to 10% with conduction
(only for IR lamps)
78
Ir.t .6
R/W
TV read in HB calibration
to 5% with conduction
(only for IR lamps in mode PA)
150
Ir.t .7
R/W
TV read in HB calibration
to 3% with conduction
(only for IR lamps in mode PA)
151
Ir.t .8
R/W
TV read in HB calibration
to 2% with conduction
(only for IR lamps in mode PA)
152
Ir.t .9
R/W
TV read in HB calibration
to 1% with conduction
(only for IR lamps in mode PA)
Power Fault ALARMS (SSR_SHORT, NO_VOLTAGE and NO_CURRENT)
7
bit
State
SSR_SHORT alarm
R
8
bit
State
NO_VOLTAGE alarm
R
9
bit
State
NO_CURRENT alarm
R
43
hd.2
R/W Enable POWER_FAULT alarms
44
dg.t
R/W
Refresh SSR SHORT
The alarm activates after 3 seconds.
45
dg.f
R/W
Time lter for NO_VOLTAGE,
SSR_OPEN and NO_CURRENT alarms
Note: set a value not less
than cycle time.
114
States of alarm ALSTATE IRQ
R
115
Status 2
R
12
bit
Reset SSR_SHORT /
NO_VOLTAGE / NO_
CURRENT/HB alarm
R/W
111
Xb.tr
R
HB alarm setpoint as function of
power on load
6
bit
State HB alarm R
4
bit
ALARM STATE
HB or POWER_FAULT
R
113
R
114
R
States of alarm ALSTATE_IRQ
OFF = Alarm off
ON = Alarm on
States of alarm ALSTATE
OFF = Alarm off
ON = Alarm on
12
bit
Reset SSR_SHORT /
NO_VOLTAGE / NO_
CURRENT/HB alarm
R/W
