START MODE
52
P.ont
R/W
SSR CONTROL MODES
14
xd.5
R/W
Enable trigger modes
19
FU.tA
R/W
15
bF.Cy
R/W
41
(t
R/W
Start modes at Power-On
Max. limit of RMS current in normal op
Min. number of cycles in BF mode
Cycle time SCR output
(only for ZC mode)
13
bit
R/W
16
PS.tn
R/W
17
PS.of
R/W
18
PS.ta
R/W
SOFTSTART or START RAMP
Duration of phase softstart ramp
Minimum non-conduction time
to reactivate phase softstart ramp
Maximum peak current limit during
phase softstart ramp
OFF = Restart not enabled
ON = Restart enabled
Restart of phase softstart ramp
FEEDBACK MODES
15
bit
R/W
46
xd.6
R/W
47
Rif.V
R/W
48
Rif.A
R/W
49
Rif.p
R/W
108
R
Feedback
reference
Voltage feedback reference
Current feedback reference
Power feedback reference
Calibration of voltage
feedback reference
OFF = Calibration not enabled
ON = Calibration enabled
Enable feedback modes
Setpoint V, I, P to be maintained on load
Note:
Values of V (I) are expressed in tenths of Volt
(Amperes)
Values of P are expressed in tenths of Watt)
22
Lo.p
R/W
10
bit
R
State of the ramp
of softstart of
phase
11
bit
R
State of the ramp
of softstart of
phase
20
DL.T
R/W
21
DL.oF
R/W
53
G.OUt
R/W
DELAY TRIGGERING
Delay triggering
(rst trigger only)
Minimum non-conduction time to
reactivate delay triggering
Gradient for control output
Minimum trigger output
OFF = Ramp off
ON = Ramp on
OFF = Ramp not ended
ON = Ramp ended
OPERATING HOURS COUNTER
161
0x.C
R
Number of operating hours
