—————— Instruction manual ——————
103
TPD32 EV
American sizes
TPD32 EV
American sizes
Filter type Code
Dimensions:
W x H x d
[mm]
Weight
[kg]
Category / Environment
/ Length of motor cable
(max)
TPD32-EV-500/600-560-2B-C-NA TPD32-EV-500/520-560-4B-C-NA EMI-690-1000 S7DGT
300x260x140
18.5 C3 / 2° / 100 m
TPD32-EV-500/600-800-2B-C-NA TPD32-EV-500/520-850-4B-C-NA EMI-690-1000 S7DGT
300x260x140
18.5 C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-D-NA TPD32-EV-500/520-1000-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1200-2B-D-NA TPD32-EV-500/520-1200-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-D-NA TPD32-EV-500/520-1500-4B-D-NA Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-1850-2B-D-NA TPD32-EV-500/520-1850-4B-D-NA
C3 / 2° / 100 m
TPD32-EV-500/600-1000-2B-E-NA ----- EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1300-2B-E-NA TPD32-EV-500/520-1300-4B-E-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-500/600-1400-2B-E-NA TPD32-EV-500/520-1350-4B-E-NA
Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-500/600-1500-2B-E-NA TPD32-EV-500/520-1500-4B-E-NA
TPD32-EV-500/600-1800-2B-E-NA TPD32-EV-500/520-1800-4B-E-NA
TPD32-EV-500/600-2000-2B-E-NA TPD32-EV-500/520-2000-4B-E-NA
TPD32-EV-500/600-2200-2B-E-NA ----- n.d.
TPD32-EV-500/600-2350-2B-E-NA TPD32-EV-500/520-2350-4B-E-NA n.d.
Mains voltage 575 V ± 10%
TPD32-EV-575/680-224-2B-B-NA TPD32-EV-575/600-224-4B-B-NA EMI-690-320 S7DGR
230x190x116
7.2 C3 / 2° / 100 m
TPD32-EV-575/680-280-2B-B-NA TPD32-EV-575/600-280-4B-B-NA EMI-690-400 S7EMI12
230x190x116
7.5 C3 / 2° / 100 m
TPD32-EV-575/680-336-2B-B-NA TPD32-EV-575/600-336-4B-B-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-575/680-400-2B-B-NA TPD32-EV-575/600-400-4B-B-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-575/680-450-2B-B-NA TPD32-EV-575/600-450-4B-B-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
C3 / 2° / 100 m
TPD32-EV-575/680-490-2B-C-NA TPD32-EV-575/600-490-4B-C-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-575/680-750-2B-C-NA TPD32-EV-575/600-750-4B-C-NA EMI-690-1000 S7DGT
300x260x140
18.5 C3 / 2° / 100 m
C3 / 2° / 100 m
TPD32-EV-575/680-980-2B-D-NA TPD32-EV-575/600-980-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-575/680-1200-2B-D-NA TPD32-EV-575/600-1200-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-575/680-1500-2B-D-NA TPD32-EV-575/600-1500-4B-D-NA Schaffner FN 3359HV-
2500-99 (or EPCOS
B84143B2500S024)
600x370x200
(650x320x221.5)
55
(105)
C3 / 2° / 100 m
TPD32-EV-575/680-1800-2B-D-NA TPD32-EV-575/600-1800-4B-D-NA
Mains voltage 690 V ± 10%
TPD32-EV-690/810-360-2B-C-NA TPD32-EV-690/720-360-4B-C-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-690/810-490-2B-C-NA TPD32-EV-690/720-490-4B-C-NA EMI-690-600 S7DGS
230x190x116
7.8 C3 / 2° / 100 m
TPD32-EV-690/810-650-2B-C-NA TPD32-EV-690/720-650-4B-C-NA EMI-690-1000 S7DGT
300x260x140
18.5 C3 / 2° / 100 m
C3 / 2° / 100 m
TPD32-EV-690/810-920-2B-D-NA TPD32-EV-690/720-980-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1200-2B-D-NA TPD32-EV-690/720-1200-4B-D-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1450-2B-D-NA TPD32-EV-690/720-1450-4B-D-NA
EPCOS
B84143B2500S021
650x385x221.5
105 C3 / 2° / 100 m
TPD32-EV-690/810-1650-2B-D-NA TPD32-EV-690/720-1650-4B-D-NA
C3 / 2° / 100 m
TPD32-EV-690/810-900-2B-E-NA TPD32-EV-690/720-900-4B-E-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1150-2B-E-NA TPD32-EV-690/720-1150-4B-E-NA EMI-690-1600 S7DGK
300x260x140
24.5 C3 / 2° / 100 m
TPD32-EV-690/810-1350-2B-E-NA TPD32-EV-690/720-1350-4B-E-NA
EPCOS
B84143B2500S021
650x385x221.5
105 C3 / 2° / 100 m
TPD32-EV-690/810-1500-2B-E-NA TPD32-EV-690/720-1500-4B-E-NA
TPD32-EV-690/810-1800-2B-E-NA TPD32-EV-690/720-1800-4B-E-NA
TPD32-EV-690/810-2000-2B-E-NA TPD32-EV-690/720-2000-4B-E-NA
TPD32-EV-690/810-2350-2B-E-NA TPD32-EV-690/720-2350-4B-E-NA n.d.
note!  TPD32-EV-FC-...:referenceshouldbemadetothecorrespondingvoltageandcurrentsizes
ofTPD32EVStandardsizes.
