gefran TPD32-EV-CU series User Manual

—————— Instruction manual ——————
233
Up
Down
Mpot output mon Mode:Last val
Start
InFollowmodewiththeStop or FastStop commandpresent,theDown commandissimulated,i.e.theoutput
oftheMotorpotentiometerfunctionmovestolowerlimitwiththesetramptime.
IftheRun commandissentthemotorpotentiometeroutputdecreaseisstoppedandthecurrentvalueusedin
additiontoRamp Ref 1 andRamp Ref 2 tosettheactualRamp Ref.
Up
Down
Mpot output mon Mode:Follow
Start
Option 2:
Thetwooperatingmodesare:Ramp or Fine.
InRampmode,eachtimetheUp or Down commandsareenabled,theoutputoftheMotorpotentiometerfunc-
tionincreasesordecreaseswiththesetramp.WhentheUp or Down commandisremoved,thelastvaluethat
wasreachedismaintained.
Up
Down
Mpot output mon Mode:Ramp
InFinemode,eachtimetheUp or Downcommandsareenabled,theoutputoftheMotorpotentiometerfunc-
tionincreasesordecreasesby1rpm.
Ifthecommandpersistsforlessthan1second,nootherchangesaremadeontheoutput.
Ifthecommandpersistsformorethan1second,theoutputincreasesordecreaseswiththesetramp.Thevaria-
tionwiththesetrampisperformedgradually(1second).WhentheUp or Downcommandisremovedthelast
valuethatwasreachedismaintained.
