—————— TPD32-EV ——————
434
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
MONITOR
Enabledrive
Enabled
Disabled
314 U16 0 1 Disabled Disabled
ü
R/W
1
0
12
H
L
R/W
1
0
Start/Stop
Start
Stop
315 U16 0 1 Stop
(0)
Stop
(0)
ü
R/W
1
0
13
H
L
R/W
1
0
MONITOR \ Measurements \ Speed \ Speed in DRC [ ]
Rampref(d)[FF]
109 I16 -32768 +32767 - -
ü
R - R
Rampoutput(d)[FF]
112 I16 -32768 +32767 - -
ü
R - R
Speedref(d)[FF]
115 I16 -32768 +32767 - -
ü
R - R
Actualspd(d)[FF]
119 I16 -32768 +32767 - -
ü
R - R
Factspd(d)[FF]
925 I16 -32768 +32767 - -
ü
R - R
Actspdlter[s]
923 Float 0.001 1.000 0.100 0.100
ü
R/W - -
MONITOR \ Measurements \ Speed \ Speed in rpm
Rampref(rpm)
110 I16 -32768 +32767 - -
ü
R QA R
Rampoutp(rpm)
113 I16 -32768 +32767 - -
ü
R QA R
Speedref(rpm)
118 I16 -32768 +32767 - -
ü
R QA R
Actualspd(rpm)
122 I16 -8192 +8192 - -
ü
R QA R
Enc1speed(rpm)
427 I16 -8192 +8192 - -
ü
R R
Enc2speed(rpm)
420 I16 -8192 +8192 - -
ü
R R
Factspd(rpm)
924 I16 -32768 +32767 - -
ü
R QA R
Actspdlter[s]
923 Float 0.001 1.000 0.100 0.100
ü
R/W - -
MONITOR \ Measurements \ Speed \ Speed in %
Rampref(%)
111 Float -200.0 +200.0 - -
ü
R - -
Rampoutput(%)
114 Float -200.0 +200.0 - -
ü
R - -
Speedref(%)
117 Float -200.0 +200.0 - -
ü
R - -
Actualspd(%)
121 Float -200.0 +200.0 - -
ü
R - -
MONITOR \ Measurements
Mainsvoltage[V]
466 U16 0 999 - -
ü
R - -
Mainsfrequency[Hz]
588 Float 0.0 70.0 - -
ü
R - -
Outputpower[Kw]
1052 Float 0.01 9999.99 - -
ü
R - -
Outputvoltage[V]
233 Float** 0 999 - -
ü
R QA R
Motorcurrent[%]
199 I16 -250 250 - -
ü
R QA R
FTcurr(%)
928 I16 -500 +500 - -
ü
R QA R
Tcurrlter[s]
926 Float 0.001 0.250 0.100 0.100
ü
R/W - -
Tcurrentref[%]
41 I16 -200 +200 - -
ü
R QA R
Fluxreference[%]
500 Float* 0.0 100.0 - -
ü
R QA -
Fluxcurrent[%]
234 Float* 0.0 100.0 - -
ü
R QA -
Fluxcurrent(A)
351 Float 0.1 99.9 S S
ü
R - -
MONITOR \ I/O
DigitalI/Q
- -
ü
- - -
Diginputterm
564 U16 0 65535 - - - R - R
Diginputterm1
565 U16 0 1 - - - R - R
Diginputterm2
566 U16 0 1 - - - R - R
Diginputterm3
567 U16 0 1 - - - R - R
Diginputterm4
568 U16 0 1 - - - R - R
Diginputterm5
569 U16 0 1 - - - R - R
Diginputterm6
570 U16 0 1 - - - R - R
Diginputterm7
571 U16 0 1 - - - R - R
Diginputterm8
572 U16 0 1 - - - R - R
Diginputterm9
573 U16 0 1 - - - R - R
Diginputterm10
574 U16 0 1 - - - R - R
Diginputterm11
575 U16 0 1 - - - R - R
