—————— Instruction manual ——————
445
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Drivetype
TPD32-EV-...-2B
TPD32-EV-...-4B
300 U16 10 11 S S - R
10
11
- R
10
11
CONFIGURATION \ Dimension fact
Dimfactornum
50 I32*** 1 65535 1 1
ü
R/Z - R
Dimfactorden
51 I32*** 1 +2
31
-1 1 1 ü R/Z - R
Dimfactortext
52 Text rpm rpm
ü
R/Z - -
CONFIGURATION \ Face value fact
Facevaluenum
54 I16 1 +32767 1 1
ü
R/Z - R
Facevalueden
53 I16 1 +32767 1 1
ü
R/Z - R
CONFIGURATION \ Prog alarms \ Failure supply
FSLatch
ON
OFF
194 U16 0 1 ON
ON
ü
R/Z
1
0
- -
FSOkrelayopen
ON
OFF
195 I16 0 1 ON ON
ü
R/W
1
0
- -
CONFIGURATION \ Prog alarms \ Undervoltage
Undervoltthr[V]
481 U16 0 1000 230 230
ü
R/W - -
UVLatch
ON
OFF
357 U16 0 1 ON ON
ü
R/Z
1
0
- -
UVOkrelayopen
ON
OFF
358 I16 0 1 ON ON
ü
R/W
1
0
- -
UVHoldofftime[ms]
470 U16 0 100 0 0
ü
R/W - -
UVRestarttime[ms]
359 U16 0 65535 1000 1000
ü
R/W - -
CONFIGURATION \ Prog alarms \ Overvoltage
OVActivity
Ignore
Warning
Disabledrive
203 U16 0 2 Ignore Ignore
ü
R/Z
0
1
2
- -
OVLatch
ON
OFF
361 U16 0 1 ON ON
ü
R/Z
1
0
- -
OVkrelayopen
ON
OFF
362 I16 0 1 ON ON
ü
R/W
1
0
- -
OVHoldofftime[ms]
482 U16 0 10000 0 0
ü
R/W - -
OVRestarttime[ms]
483 U16 0 10000 0 0
ü
R/W - -
CONFIGURATION \ Prog alarms \ Overspeed
Overspeedthr[rpm]
1426 U16 0 32767 4000 4000
ü
R/W - -
OSActivity
Ignore
Warning
Disabledrive
Quickstop
Normalstop
Currlimstop
1422 U16 0 2 Ignore Ignore
ü
R/Z
0
1
2
3
4
5
- -
OSLatch
ON
OFF
1421 U16 0 1 ON ON
ü
R/Z
1
0
- -
OSOkrelayopen
ON
OFF
1423 I16 0 1 ON ON
ü
R/W
1
0
- -
OSHoldofftime[ms]
1424 U16 0 10000 0 0
ü
R/W - -
OSRestarttime[ms]
1425 U16 0 10000 0 0
ü
R/W - -
CONFIGURATION \ Prog alarms \ Heatsink
HSActivity
Warning
Disabledrive
Quickstop
Normalstop
Currlimstop
368 U16 1 5 Disable
drive
Disable
drive
ü
R/Z
1
2
3
4
5
- -
