rial rated for this temperature.
Latempératuredudissipateurdechaleurdel’inverseurpeutatteindre194°F/90°Cpendantle
fonctionnement;veilleràutiliserunmatériauisolantcompatibleaveccettetempérature.
3.3. External View
(a)Sizes1and2(230VClass:0.75~5.5kW/400VClass:0.75~5.5kW)
Fan cover
Mounting hole
Heatsink
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Fan cover
Mounting hole
Rings (4 rings)
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Anti-dust cover
(Wall-mounted type, IEC IP20) (Wall-mounted type, IEC IP20, NEMA1)
(b)
Sizes3and4(230VClass:7.5~18.5kW/400VClass:7.5~22kW)
Mounting hole
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Mounting hole
Nameplate
and barcode
Front cover
Keypad
Terminal
cover
Anti-dust cover
(Wall-mounted type, IEC IP20) (Wall-mounted type, IEC IP20, NEMA1)
14 VDI100 • Instruction manual
