6.6. ChangeFrequencyUnitfromHztorpm
Enter the number of motor poles in 16-03 to change the display units from Hz to rpm.
Code Parameter Name / Range
16-03 Display unit
0: Display unit is Hz (Resolution is 0.01Hz)
1: Display unit is % (Resolution is 0.01%)
2: Frequency display unit is rpm
3~39: Display unit rpm, (uses number of motor poles to calculate)
40~9999: 100% is XXXX with no decimals (integer only)
10001~19999: 100% is XXX.X with 1 decimal
20001~29999: 100% is XX.XX with 2 decimals
30001~39999: 100% is X.XXX with 3 decimals
Example: Motor poles 4, 16-03 = 4.
VDI100 • Instruction manual 315
