Automatic operation frequency reference settings
Code Parameter Name / Range
06-01 Frequency setting of speed-stage 1
06-02 Frequency setting of speed-stage 2
06-03 Frequency setting of speed-stage 3
06-04 Frequency setting of speed-stage 4
06-05 Frequency setting of speed-stage 5
06-06 Frequency setting of speed-stage 6
06-07 Frequency setting of speed-stage 7
06-08 Frequency setting of speed-stage 8
06-09 Frequency setting of speed-stage 9
06-10 Frequency setting of speed-stage 10
06-11 Frequency setting of speed-stage 11
06-12 Frequency setting of speed-stage 12
06-13 Frequency setting of speed-stage 13
06-14 Frequency setting of speed-stage 14
06-15 Frequency setting of speed-stage 15
0.00~599.00 Hz
Automatic operation time settings
06-16 Operation time setting of speed-stage 0
06-17 Operation time setting of speed-stage 1
06-18 Operation time setting of speed-stage 2
06-19 Operation time setting of speed-stage 3
06-20 Operation time setting of speed-stage 4
06-21 Operation time setting of speed-stage 5
06-22 Operation time setting of speed-stage 6
06-23 Operation time setting of speed-stage 7
06-24 Operation time setting of speed-stage 8
06-25 Operation time setting of speed-stage 9
06-26 Operation time setting of speed-stage 10
06-27 Operation time setting of speed-stage 11
06-28 Operation time setting of speed-stage 12
06-29 Operation time setting of speed-stage 13
06-30 Operation time setting of speed-stage 14
06-31 Operation time setting of speed-stage 15
0.0~6000.0 s
Automatic operation direction settings
06-32 Operation direction selection of speed-stage 0
06-33 Operation direction selection of speed-stage 1
06-34 Operation direction selection of speed-stage 2
06-35 Operation direction selection of speed-stage 3
06-36 Operation direction selection of speed-stage 4
06-37 Operation direction selection of speed-stage 5
06-38 Operation direction selection of speed-stage 6
06-39 Operation direction selection of speed-stage 7
06-40 Operation direction selection of speed-stage 8
06-41 Operation direction selection of speed-stage 9
06-42 Operation direction selection of speed-stage 10
06-43 Operation direction selection of speed-stage 11
06-44 Operation direction selection of speed-stage 12
06-45 Operation direction selection of speed-stage 13
06-46 Operation direction selection of speed-stage 14
06-47 Operation direction selection of speed-stage 15
0: Stop, 1: Forward, 2: Reverse
188 VDI100 • Instruction manual
