Initialization of Cumulative Energy of 11-54 can clear these monitoring parameters.
Monitoring parameter 12-38: PID setting & 12-39: PID Feedback
Refer to the setting of 10-33~10-35.
Monitoring parameter 12-76: No-Load Voltage Output
It is required to be with the descriptions of parameter 02-09 (excitation current of motor 1) and parameter 17-09
(motor excitation current).
Monitoring parameter 12-78: Z-Phase Bias Value
It is required to be with the parameter 21-43 (Offset Angle).
Monitoring parameter 12-79: Pulse Input Percentage
Refer to parameter 03-30 (Selection of pulse input)
Note: It can perform run command when viewing monitoring parameters (12-05~12-79).
240 VDI100 • Instruction manual
