Gemu 1435 ePos - Quick Commissioning

2 / 48
1435 e Pos
Quick commissioning of the GEMÜ 1435 ePos:
Prerequisites:
● Mounted to the valve
● Air supply, max. 6bar, connected
● 24 V DC supply voltage connected
● Set value signal need not be connected
● For correct commissioning proceed as described in the following flow chart:
The GEMÜ 1435 ePos
positioner is ready for
operation and reacts to
the externally specified
set value.
P = 45.4
D: NO INIT
Nach dem Einschalten
PRESS -> FOR 3s
C: CONFIG
länger als 3s drücken
1: SETPOINT
NO INIT
2: INIT ALL
PRESS -> FOR 3s
2: INIT ALL
P = XX.X
2: INIT RUN 1
P = XX.X
2: INIT RUN 2
up -> down
2: INIT RUN 3
down -> up
2: INIT RUN 3
P = XX.X
2: INIT RUN 4
P = XX.X
2: INIT RUN 5
INIT OK
2: INIT ALL
1: SETPOINT
PRESS -> FOR 3s
C: CONFIG
X = 55.5
B: MANUAL. W = 55.5
.. .... X = 30.5
A: AUTO. W = 30.5
länger als 3s drücken
press for more than 3 seconds
press for more than 3 seconds
After switching on
