1435 e Pos
10.3 Parameter table
Config. level Display Function Value range Factory setting read write
Mode Select operating mode
AUTO
MAN
AUTO 0 3
1 Service
I / O Status
Submenu for displaying inputs and outputs
min-Pot-max
Displays travel sensor position in
percent
0 o.r.*
I w / Uw Value of set value signal in mA / V 0 o.r.*
W Pos X
Comparison of set value and
valve position
0 o.r.*
Pot Abs Travel sensor position 0 o.r.*
Valve
Displays the current position of
the internal pilot valves
0 o.r.*
Pos Ctrl Out
Deviation between set value and
actual value (positioner)
0 o.r.*
Relais K1:K2:Err
Displays the current position of
the internal outputs
0 o.r.*
Login
Submenu for setting access authorisations
Code Password entry 0...10000 0 0 0
Logout Block access OK 0 0
New Code: 1 Release the lowest priority 0...10000 0 1 1
New Code: 2 Release the medium priority 0...10000 0 2 2
New Code: 3 Release the top priority 0...10000 0 3 3
Diagnosis
Submenu for displaying diagnostic messages
Error List Displays error messages 0 o.r.*
hrs Displays operating hours 0 o.r.*
Warnings
Display warnings during
operation
ON / OFF ON 0 3
Errors Display errors during operation ON / OFF ON 0 3
Clear Error List Delete error list OK 0 3
1435 specific
Submenu for displaying the tool identification
Release Displays current software release V2.0.0 0 o.r.*
S/N Displays current serial number 0 o.r.*
TAG1 A TAG number can be entered 0 3
TAG2 A TAG number can be entered 0 3
Config. level Display Function Value range Factory setting read write
2 SetBasics
Setpoint Type of set value signal
4-20 mA
0-20 mA
0-10 V
4-20 mA 0 3
Default Reset to factory settings Yes / No Yes 3 3
Init All
Submenu for carrying out the initialisation
GoClose
Scanning the closed position
3 3
GoOpen Scanning the open position 3 3
AdjTime Scanning the operating times 3 3
FindCoefficent
Optimization of control
characteristics
3 3
InitPilot
Setting the minimum operating
times for internal pilot valves
3 3
CalPointQty
Quantity of calibration points
when initialising
1...19 2 3 3
D.Refresh Time for display refresh 0.1...1.0 s 0.5 s 0 1
Systemmode Type of operator interface Classic / Advanced Classic 0 3
DLight Setting the display lighting OnKey / On OnKey 0 2
DLightTime
Time for switching off display
lighting during adjustment
[OnKey]
1...60 min 5 min 0 2
HelpLanguage Text language D / GB D 0 1
HelpText Display the help text ON / OFF ON 0 1
* only readable
