5 / 48
1435
e
Pos
1.4 Correct use
7 The GEMÜ 1435 ePos serves solely as a positioner and
must be used according to the data sheet.
7 The GEMÜ 1435 ePos must not be used outdoors without
heating element. The version with heating element may only
be used outdoors in a rain-protected area.
7 Any other use or use above and beyond this is not
permitted. GEMÜ shall not be liable for any consequential
damage which is solely at the user's risk.
7 Please pay attention to the pertinent technical safety
regulations when planning both the use and operation of the
device. The designer, plant constructor or operator is always
responsible for positioning and mounting of the GEMÜ
1435 ePos.
1.5 Information on use in damp conditions
Under no circumstances whatsoever may the
GEMÜ 1435 ePos be cleaned with a high pressure
cleaning device because the protection class IP 65
is not suffi cient for this.
The following information is intended to help when mounting
and operating the GEMÜ 1435 ePos in damp conditions:
● The GEMÜ 1435 ePos must be protected from direct impact
of rain water.
● Lay cables and and pipework so that condensate or rain
water that remains on the pipework / cables cannot enter
the cable glands of the M12 plugs of the GEMÜ 1435 ePos.
● Check that all cable glands of the M12 plug and the fi ttings
are mechanically secured.
● Check housing seal for correct position and damage each
time before closing.
● Close keypad cover properly immediately after use.
● Lock all covers (throttles, check valve) immediately after use.
1.6 Mounting position
The mounting position of the GEMÜ 1435 ePos is optional.
When mounted upside down it must be ensured that no liquids
or dirt can enter the outlet of the pressure relief valve.
1.7 Tools required for installation and assembly
The tools required for installation and assembly are not
included in the scope of delivery.
Open-end wrench SW10 and SW27
Allen key 3 mm and 4 mm
Electric screwdriver 3.5 mm
2 Manufacturer's information
2.1 Transport
l
Only transport the positioner by suitable means. Do not
drop. Handle carefully.
l Dispose of packing material according to relevant local or
national disposal regulations / environmental protection
laws.
2.2 Delivery and performance
l
Check that all parts are present and check for any damage
immediately upon receipt.
l The scope of delivery is apparent from the dispatch
documents and the design from the order number.
l The performance of the positioner is checked at the factory.
● If the GEMÜ 1435 ePos positioner is ordered as a complete
unit with a valve, these parts and the accessories belonging
to them are supplied ready assembled and factory set. The
GEMÜ positioner is then ready for immediate operation.
2.3 Storage
l
Store the positioner free from dust and moisture in its
original packaging.
l Avoid UV rays and direct sunlight.
l Maximum storage temperature: 60 °C.
2.4 Function
The GEMÜ 1435 ePos is an intelligent electro-pneumatic
positioner designed for mounting to pneumatic linear and
quarter turn actuators.
The positioner can be directly mounted to the actuator using
a suitable mounting kit. The mounting kit contains both the
mounting bracket / adapter and the appropriate travel sensor
with the relevant fastening screws.
Remote mounting is also possible, whereby the mounting
bracket / adapter is not needed.
The travel sensor measures the current position of the valve
and relays this position to the electronic control system of the
GEMÜ 1435 ePos which correlates the actual value of the
valve with the set value and adjusts the valve if necessary.
The information required can be called-up on the two-line
display of the GEMÜ 1435 ePos. Self-explanatory help texts
that explain the meaning of the parameters called-up are also
displayed.
The GEMÜ 1435 ePos is operated using four keys.
2.5 Fail safe function
The GEMÜ 1435 ePos has a fail safe function which ensures
that the outlets are vented during a pneumatic and electrical
power supply failure.
This fail safe function is not a substitute for specifi c plant safety
requirements. The GEMÜ 1435 ePos is not a safety control
system.
