1435 e Pos
Config. level Display Function Value range Factory setting read write
3 SetFunction
PosCtrl
Submenu for setting positioner parameters
Prop Gain P amplification of the positioner 0.1...100.0 X.X 0 3
Deriv Time
Decay time of the D component
of the positioner
0.00...10.00 s
0.1 s 0 3
MinPos
Seal adjuster = lower position of
control range
0...100 % 0.0 % 0 3
MaxPos
Stroke limiter = upper position
of control range
0...100 % 100 % 0 3
CloseTight Close tight function
no
Min / Max
Max
Min
no 0 3
DeadBand Permissible system deviation
0,0...10 %
auto
1,0 % 0 2
AlarmOutput
Submenu for setting the alarm outputs
Alarm Fn
Determines the function of the
alarm output
OFF
Min / max
Min / min
Max / max
OFF 0 2
Level Alarm 1 Switch point of alarm 1 0.0...100.0 % 10.0 % 0 1
Level Alarm 2 Switch point of alarm 2 0.0...100.0 % 90.0 % 0 1
Error Output
Submenu for setting the error output
Error Functn
Determines the function of the
error message output (ERROR)
Error
Error+Inactive
Range
Error+Range
Err+Range+Inac
ERROR+ RANGE 0 3
Error Time
Valve travel time monitoring
( Error message output)
AUTO
0.0...100.0 s
AUTO 0 3
Error Level
Maximum system deviation
( Error message output)
AUTO
0.0...100.0 %
AUTO 0 3
Range Functn
Range monitoring of set value
input
< 4 mA
> 20 mA
< 4 mA or > 20 mA
< 4 mA or > 20 mA 0 3
Position Output
Submenu for setting the actual value output
Analog Out
Determines the function of the
actual value output
0-10 V
0-20 mA*
4-20 mA
0-10 V 0 2
Out min
Valve position on actual value
output signal 0 V (0/4 mA*)
0.0...100.0 % 0.0 % 0 2
Out max
Valve position on actual value
output signal 10 V (20 mA*)
0.0...100.0 % 100.0 % 0 2
CpyParaSet
Copies parameters to various
working memories (P1/P2/P3/
P4)
3 3
* Only available on version with optional current output
