Controller Operation
Fault Description
Charger ID 0 to 3 Common Electrical Trip
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a battery charger connected by DSE-
Net® had issued a Common Electrical Trip Alarm.
Combined Mains Decoupling The module detected that the mains supply failed when the gen-
erator was in parallel with it.
Coolant Temp High
IEEE C37.2 – 26 Apparatus Thermal Device
The module detected that the engine coolant temperature had
risen above the High Coolant Temperature Electrical Trip level
after the Safety On Delay timer had expired.
DEF Level Low The module received a fault condition from the engine ECU
alerting about the DEF level.
Digital Input A to L
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that a digital input configured to create a
fault condition became active and the appropriate LCD mes-
sage is displayed.
DPTC Filter The module received a fault condition from the engine ECU
alerting that the DPF/DPTC had activated.
ECU Amber The module received an amber fault condition from the engine
ECU.
ECU Data Fail The module is configured for CAN operation but has not de-
tected data being sent from the engine’s ECU.
ECU Malfunc. The module received a malfunction fault condition from the en-
gine ECU.
ECU Protect The module received a protect fault condition from the engine
ECU.
ECU Red The module received a red fault condition from the engine ECU.
Engine Under Speed
IEEE C37.2 - 14 Underspeed Device
The module detected that the engine speed had fallen below
the Under Speed Alarm Trip level for the configured delay timer
after the Safety On Delay timer had expired.
Exp. Unit Failure The module detected that communications to one of the DSE-
Net® expansion modules had been lost.
Fail to Synchronise The module failed to synchronise the generator before the Fail
to Sync Delay timer had expired.
Flexible Sensor A to D High
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that an analog input value had risen
above the Flexible Sensor High Alarm Trip level.
18 Deep Sea Electronics® G8601 Controller Owner’s Manual
