Controller Operation
Fault Description
Flexible Sensor A to D Low
NOTE: Due to module configuration the alarm message that ap-
pears on the display may be different. For further details of mod-
ule configuration, contact your Authorized Industrial Service
Dealer (IASD).
The module detected that an analog input value had fallen be-
low the Flexible Sensor Low Alarm Trip level.
Fuel Level High
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the engine fuel level had risen the
High Fuel Level Alarm level for the configured delay.
Fuel Level Low
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the engine fuel level had fallen below
the Low Fuel Level Alarm level for the configured delay.
Fuel Level Low Switch
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the engine low fuel level switch had
activated.
Fuel Tank Bund Level High
IEEE C37.2 - 71 Liquid Level Switch
The module detected that the fuel tank bund level switch had
activated.
Fuel Usage
IEEE C37.2 – 80 Flow Switch
The module detected that the fuel consumption was more than
the configured Running Rate or Stopped Rate.
Gen Earth Fault
IEEE C37.2 – 51G or 51N Generator IDMT
Earth Fault Relay
The module detected that the generator earth fault current had
risen above the Earth Fault Trip Level for the duration of the
IDMT function.
Gen Failed to Close
IEEE C37.2 – 52b AC Circuit Breaker Position
(Contact Open when Breaker Closed)
The module detected that the generator load switch had failed
to close as the Generator Closed Auxiliary input did not activate
within the Generator Fail to Close Delay time after the Close
Gen Output activated.
Gen Loading Frequency The module detected that the generator output frequency had
not risen above the Generator Loading Frequency setting after
the Warming Up timer had expired.
Gen Loading Voltage The module detected that the generator output voltage had not
risen above the Generator Loading Voltage setting after the
Warming Up timer had expired.
Gen Over Current
IEEE C37.2 – 51 IDMT Overcurrent Relay The module detected that the generator output current had ris-
en above the Generator Over Current Trip for the duration of
the IDMT function.
Gen Phase Seq Wrong
IEEE C37.2 – 47 Phase Sequence Relay
The module detected that the phase rotation of the generator
was different to the configured Generator Phase Rotation Alarm
setting.
Gen Short Circuit
IEEE C37.2 – 51 IDMT Short Circuit Relay The module detected that the generator output current had ris-
en above the Short Circuit Trip for the duration of the IDMT
function.
Inlet Temperature The module detected that the engine’s ECU measurement of in-
let temperature had risen above the Inlet Temperature Alarm
Trip level.
Insufficient Capacity The module’s governor output has reached its limit whilst at-
tempting to control the generator to produce more kWs whilst in
parallel. This indicates a fault with either the governor (including
connection error), setting of SW2, or that the engine has
reached its maximum capacity.
Deep Sea Electronics® G8601 Controller Owner’s Manual 19
