Generac Power Systems Deep Sea Electronics G8601

Controller Operation
52 2.5 mm²
AWG 13
CT Secondary for Generator
L1
53 2.5 mm²
AWG 13
CT Secondary for Generator
L2
54 2.5 mm²
AWG 13
CT Secondary for Generator
L3
55 2.5 mm²
AWG 13
Earth Fault Measuring
56 2.5 mm²
AWG 13
Earth Fault Measuring
57 2.5 mm²
AWG 13
CT Secondary for BUS L1
58 2.5 mm²
AWG 13
CT Secondary for BUS L2
59 0.5 mm²
AWG 20
Configurable Digital Input A
60 0.5 mm²
AWG 20
Configurable Digital Input B
61 0.5 mm²
AWG 20
Configurable Digital Input C
62 0.5 mm²
AWG 20
Configurable Digital Input D
63 0.5 mm²
AWG 20
Configurable Digital Input E
64 0.5 mm²
AWG 20
Configurable Digital Input F
65 0.5 mm²
AWG 20
Configurable Digital Input G
66 0.5 mm²
AWG 20
Configurable Digital Input H
67 0.5 mm²
AWG 20
Configurable Digital Input I
68 0.5 mm²
AWG 20
Analog Sensor Input E
69 0.5 mm²
AWG 20
Analog Sensor Input F
70 0.5 mm²
AWG 20
Analog Sensor Input G
RS485
1
71 Shield RS-485 Port 1 Screen
72 0.5 mm²
AWG 20
RS-485 Port 1 B (+)
73 0.5 mm²
AWG 20
RS-485 Port 1 A (-)
28 Deep Sea Electronics® G8601 Controller Owner’s Manual
