Controller Operation
RS485
2
74 Shield RS-485 Port 2 Screen
75 0.5 mm²
AWG 20
RS-485 Port 2 B (+)
76 0.5 mm²
AWG 20
RS-485 Port 2 A (-)
77 0.5 mm²
AWG 20
Sensor Common Return for
Analog Sensor Inputs E, F, G
