2 0F5083 1 DECALHTS T/SWITCH NEMA 1
0G2749 1 DECALHTS T/SWITCH NEMA 1 P/L
3 0F4284 1 KEYPAD, COMM XFER SW IN-PHASE
4 095282 1 DECAL-LIVE CIRCUIT
5 0F4302 1 KEYPAD INTERFACE ASSY
6 0F4460 2 SPACER PCB M4/#8X5/16X1/4 NYL
7 0536210193 1 ASSY WIRE #0 12.00"(GROUND WIRE)
8 077228 1 DECAL-ENCLOSURE NOTE
9 0F5508A 1 DECAL HTS TEST SEQUENCE 100A
0F5508B 1 DECAL HTS TEST SEQUENCE 150A
0F5508C 1 DECAL HTS TEST SEQUENCE 200A
0F5508D 1 DECAL HTS TEST SEQUENCE 300A
0F5508E 1 DECAL HTS TEST SEQUENCE 400A
10 0F5503 1 DECAL HTS SWITCH INFO
11 0D4545 1 DECAL, MANUAL OPERATION
12 063321 1 HANDLE XFER SWITCH 1-400A
13 0F4801 1 PLATE MOUNTING PCB ASSEMBLY
14 0F5926 1 ASSY PCB COVER COMM XFER SW
15 0F5901 1 ASSY COVER COMM XFER SW
16 0F5180 1 BATTERY, AAA
(1)17 0F4410 1 ASSY PCB COMM TRANSFORMER
(1)18 0H6017 1 OTS RELAY-COMM XFER SWITCH W
19 0F4802 1 BRACKET TOGGLE SWITCH
20 0D3610 1 DECAL, MAINTENANCE DISCONNECT
(1)21 055868 1 SWITCH TOGGLE 4PDT 15A SPADE
22 063971 1 RES 250R 5% 100W
23 063324 2 RES MTG BRACKET FOR 100W
24 064126 2 TRANSFRM 240/480V-120/240V
072162 2 TRANSFRM 600V TO 240V 200VA
(1)25 046357 REF BLOCK TERM 20A 6 X 6 X 1100V
26 0F5039 1 DECAL CT CONNECTIONS
(1)27 027911 REF RELAY PNL 12VDC DPDT 10A@240VA
28 064510 1 DECAL-TERMINAL NOTE
29 063578 1 PLATE DATA - GTS
30 054199 1 DECAL, DANGER HIGH VOLTAGE
31 062209 1 DECAL UL LABEL E84929-GTS
32 083736 1 DECAL-CSA GTS
33 062684 1 LUG SLDLSS 2/0
057329 1 LUG SLDLSS 350
34 067210A 1 DECAL, GND
(1)35 046689 REF BLOCK TERM 20A 4 X 6 X 1100V
36 0H6016 1 DECAL (RS485 & 2WS)
37 075355 1 DECAL SIGNAL BEFORE XFER
38 0E3717 1 ASSY NEUT BLK 100A W/TAP
0E3717A 1 ASSY NEUT BLK 200-400A W/TAP
0F4034 1 ASSY TERMINAL BLOCK 300-400A
39 0A9457 1 DECAL NEUTRAL
40 091472 FT DUCT WIRING 1X1.5 (34"=2.833FT)
41 091472A FT COVER WIRE DUCT 1 IN (34"=2.833FT)
42 0D7300 1 XFER SW W 100A600V2P
0D7301 1 XFER SW W 100A600V3P
0D7302 1 XFER SW W 100A600V4P
0C8881 1 XFER SW W 150A600V2P
0C8882 1 XFER SW W 150A600V3P
0C8883 1 XFER SW W 150A600V4P
0C8884 1 XFER SW W 200A600V2P
0C8885 1 XFER SW W 200A600V3P
0C8886 1 XFER SW W 200A600V4P
0D7297 1 XFER SW W 300A600V2P
0D7298 1 XFER SW W 300A600V3P
0D7299 1 XFER SW W 300A600V4P
0D7294 1 XFER SW W 400A600V2P
0D7295 1 XFER SW W 400A600V3P
0D7296 1 XFER SW W 400A600V4P
43 099084 REF LUG SLDLSS 2/0
0A9949 REF LUG SLDLSS 400
0A7822 REF LUG SLDLSS 600/250
44 0C7907A 2 COVER LUG 2P 100AMP
0C7907B 2 COVER LUG 3P 100AMP
0C7907C 2 COVER LUG 4P 100AMP
0C7907H 2 COVER LUG 2P 150/200AMP
0C7907J 2 COVER LUG 2P 300/400AMP
0C7907F 2 COVER LUG 3P 300/400AMP
0C7907G 2 COVER LUG 4P 300/400AMP
45 0C8308 2 DECAL TERMINAL SHOCK HAZARD
46 0F6776A 1 DECAL DIP SW. CONFIG. PCB COVER
47 0F6776B 1 DECAL DIP SW. CONFIG. ENCL
48 0G1484 1 DECAL UL CTRL PANEL ENCL
49 0F9340 1 TAG, BATTERY DISCONNECT
50 074604 1 AUX CONTACT N-TYP SPDT
51 074672A 2 SWITCH MICRO DPDT SEL & AUX2PL
52 092979 1 AUX CONT INSULATOR ( 300A->)
(1)53 0H6400HD 1 WIRE HARNESS HTS (NOT SHOWN)
HARDWARE
100 0C6748 2 NUT HEX LOCK M4-0.7 SS NYL INS
101 022985 REF WASHER FLAT #6 ZINC
102 022264 REF WASHER LOCK #8-M4
103 0F7806 2 NUT HEX FL WHIZ M4-0.7
104 087680 1 NUT WING M6-1.0
105 0D6511 12 SPACER .20 X .375 X .375 PL
106 0E6423 12 NUT HEX FL WHIZ M5-0.8
107 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
108 0A2111 4 SCREW SWAGE #10-32 X 5/16 ZYC
109 056893 8 SCREW CRIMPTITE 10-24 X 1/2
110 0A1661 REF RIVET POP .156 X .675 AL
111 0C8275 4 SCREW PPHM DSEMS M4-7 X 10 ZNC
112 027482 1 WASHER SHAKEPROOF EXT 5/16 STL
113 024526 1 SCREW HHTT 5/16-18 X 3/4 CZ
114 022473 REF WASHER FLAT 1/4-M6 ZINC
115 074906 5 SCREW HHTT M6-1.0 X 20 BP
116 067989 REF NUT HEX FL WHIZ M8-1.25
117 063378 6 HOLDER CABLE TIE
118 091477 11 RIVET, WIRE DUCT MNT
119 0F5272 2 CLAMP CABLE FLAT
120 022473 3 WASHER FLAT 1/4-M6 ZINC
121 022097 REF WASHER LOCK M6-1/4
122 0C4896 REF SCREW FHM M8-1.25 X 20MM CR
123 026902 REF SCREW HHTT #8-32 X 1/4 CZ
124 0A8261 REF SCREW HHC 1/4-28 X 5/8 .625TH
125 029333A 2 TIE WRAP UL 7.4"X .19" BLK
126 092980 REF SCREW PPHM M4-0.7 X 25
(1)DESIGNATES ITEMS STRUCTURED IN
WIRE HARNESS (NOT SHOWN).
