Generac Power Systems HTS User Manual

1
0F6610
1
ENCL NEMA 12 36X66X20
0F7312 1 ENCL NEMA 3R 36X66X20
2 0F5083 1 DECAL,HTS T/SWITCH NEMA 1
0G2749 1 DECAL,HTS T/SWITCH NEMA 1 P/L
0F7145 1 DECAL,HTS T/SWITCH NEMA 3R
0G2774 2 DECAL,HTS T/SWITCH NEMA 3R P/L
3 0F4284 1 KEYPAD, COMM XFER SW IN-PHASE
4 095282 1 DECAL-LIVE CIRCUIT
5 0F4302A 1 KEYPAD INTERFACE ASSY
6 0F4460 1 SPACER PCB M4/#8X5/16X1/4 NYL
7 0536210193 1 ASSY WIRE #0 12.00"(GROUND WIRE)
8 077228 1 DECAL-ENCLOSURE NOTE
0E8594 1 DECAL-ENCLOSURE NOTE NEMA 3R
9 0F5508F 1 DECAL HTS TEST SEQUENCE 600A
0F5508G 1 DECAL HTS TEST SEQUENCE 800A
0F5508H 3 DECAL HTS TEST SEQUENCE 1000A
10 0F5503 1 DECAL HTS SWITCH INFO
11 0D4545 1 DECAL, MANUAL OPERATION
12 072164 1 MNL HNDL 6-1600A WN(SUPPLIED W/SW)
13 0F4801 1 PLATE MOUNTING PCB ASSEMBLY
14 0F5926 1 ASSY PCB COVER COMM XFER SW
15 0F5901 8 ASSY COVER COMM XFER SW
16 0F5180 1 BATTERY, AAA
(1)17 0F4410 2 ASSY PCB COMM TRANSFORMER
(1)18 0H6017A REF OTS RELAY-COMM XFER SWITCH WN
19 0F4802 1 BRACKET TOGGLE SWITCH
20 0D3610 REF DECAL, MAINTENANCE DISCONNECT
(1)21 055868 1 SWITCH TOGGLE 4PDT 15A SPADE
22 0F6685 1 TIE-WRAP MOUNT FIR TREE (STYLE)
23 0F9340 1 TAG, BATTERY DISCONNECT
24 074652 1 TRANSFRM 600V TO 240V 250VA
064932 1 TRANSFRM 480/240V 250VA
(1)25 046357 1 BLOCK TERM 20A 6 X 6 X 1100V
26 0F5039 1 DECAL CT CONNECTIONS
(1)27 027911 1 RELAY PNL 12VDC DPDT 10A@240VA
28 064510 2 DECAL-TERMINAL NOTE
29 063578 1 PLATE DATA - GTS
30 054199 1 DECAL, DANGER HIGH VOLTAGE
31 062209 1 DECAL UL LABEL E84929-GTS
32 083736 1 DECAL-CSA GTS
33 0D6584 1 ASSY GRD.TERM.1600-2600A
34 067210A 1 DECAL, GND
(1)35 046689 REF BLOCK TERM 20A 4 X 6 X 1100V
36 0H6016 1 DECAL (RS485 & 2WS)
37 075355 1 DECAL SIGNAL BEFORE XFER
38 0D8700 1 ASSY NEUTRAL BLK 600-1000A ATS
39 0A9457 1 DECAL NEUTRAL
40 091472 FT DUCT WIRING 1X1.5 (33"=2.750FT)
41 091472A FT COVER WIRE DUCT 1 IN (33"=2.750FT)
42 072111 1 XFRSW 600A 3P WN600V
072117 1 XFRSW 600A 4P WN600V
072112 1 XFRSW 800A 3P WN600V
072118 1 XFRSW 800A 4P WN600V
072113 1 XFRSW1000A 3P WN600V
072119 1 XFRSW1000A 4P WN600V
43
080433
REF
LUG SLDLSS 500
-
#1X13/32 AL/CU
063925 REF LUG SLDLSS 500-4/0X17/32 AL/CU
44 074349A 2 SW CVR WN 600A 3P
074349B 2 SW CVR WN 600A 4P
074349C 2 SW CVR WN 800/1000A 3P
074349D 2 SW CVR WN 800/1000A 4P
45 0C8308 2 DECAL TERMINAL SHOCK HAZARD
46 0G7015 1 TVSS ASSEMBLY 600-2600A
47 0F6888 1 SUB-PLATE HTS 600-1000A
48 0F6776A 1 DECAL DIP SW. CONFIG. PCB COVER
49 0F6776B 1 DECAL DIP SW. CONFIG. ENCL
50 063986 4 KNOB,COVER HOLD-DOWN
51 074351 2 CVR BRKT 600-1600A RH
52 074351A 2 CVR BRKT 600-1600A LH
53 074604 1 AUX CONTACT N-TYP SPDT
54 074672A 2 SWITCH MICRO DPDT SEL & AUX2PL
55 092979 1 AUX CONT INSULATOR (300A->)
56 0G1484 1 DECAL UL CTRL PANEL ENCL
(1)57 0H6440HD 1 WIRE HARNESS HTS 6-1000A(NOT SHOWN)
HARNESS
100 0C6748 2 NUT HEX LOCK M4-0.7 SS NYL INS
101 022985 2 WASHER FLAT #6 ZINC
102 022264 2 WASHER LOCK #8-M4
103 0F7806 2 NUT HEX FL WHIZ M4-0.7
104 087680 1 NUT WING M6-1.0
105 0D6511 12 SPACER .20 X .375 X .375 PL
106 0E6423 12 NUT HEX FL WHIZ M5-0.8
107 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
108 0A2111 2 SCREW SWAGE #10-32 X 5/16 ZYC
109 0C2267 8 SCREW HHTT M5-0.8 X 12 BP
110 0A1661 REF RIVET POP .156 X .675 AL
111 022152 8 WASHER LOCK #10
112 024469 8 WASHER SHAKEPROOF EXT 5/16 STL
113 022302 REF WASHER LOCK 7/16
114 026209 REF SCREW HHC 7/16-14 X 1-3/4 G5
115 022509 REF NUT HEX 7/16-14 STEEL
116 067989 REF NUT HEX FL WHIZ M8-1.25
117 063378 8 HOLDER CABLE TIE
118 091477 7 RIVET, WIRE DUCT MNT
119 0F5272 4 CLAMP CABLE FLAT
120 042911 3 SCREW HHC M10-1.5 X 30 G8.8
121 046526 3 WASHER LOCK M10
122 092980 2 SCREW PPHM M4-0.7 X 25
123 026902 7 SCREW HHTT #8-32 X 1/4 CZ
124 029333A 2 TIE WRAP UL 7.4"X .19" BLK
125 064101 REF NUT HEX FL WHIZ 3/8-16
126 022195 REF WASHER LOCK 1/2
127 022196 REF NUT HEX 1/2-13 STEEL
128 023316 REF SCREW HHC 1/2-13 X 4 G5
(1)DESIGNATES ITEMS STRUCTURED IN WIRE HARNESS (NOT SHOWN).
