Setup and Operation
Installation and User’s Manual for Wi-Fi Module 9
Wi-Fi Setup at Generator
Controller
Connect to Home Network When
Internet is Available on the Mobile
Device
The Wi-Fi connection process varies
depending on when it is performed:
• during initial setup and configuration of a
newly-installed generator, or
• on a previously installed and operating
generator.
As part of the generator installation process, it
is recommended to connect Wi-Fi during the
initial generator setup and power-up. The
activation code will automatically be
communicated to the generator controller
through Wi-Fi communication, provided the
generator has been registered and activated
at www.activategen.com prior to making the
Wi-Fi connection. It also allows the user to
select the operating time zone immediately,
keeping exercise time on track and adjusting
for Daylight Savings Time as needed.
Begin the connection process by following the
applicable steps in the following table.
Newly Installed Generator Previously Installed Generator
1. After the controller is powered up, the
“Install Wizard” screen will appear,
followed by a prompt to select the desired
language (
Figure 3-3
).
Figure 3-3. Select Language
2. Select the desired language, press
ENTER, and proceed to the “Setup Wi-fi”
prompt (Figure 3-4
)
.
Figure 3-4. Setup Wi-Fi Prompt
3. Proceed to Continue Connection
Process.
1. See
Figure 3-5
. On the controller, press
ESCAPE to access the first level options
menu. Select “Setup Wifi?” and press
ENTER.
Figure 3-5. First Level Options Menu
2.
See
Figure 3-6
. Select “Yes?” and press
ENTER.
Figure 3-6. Setup Wi-Fi Prompt
3. Proceed to Continue Connection
Process.
