Owner’s Manual for Generac PWRcell Inverter 5
General Information
Section 2: General Information
Specifications
Description Units X7600 Series X11400 Series
Max. cont. AC power @ 50ºC kW 7.6 11.4
Grid Voltage VAC 120/240 (1-ph) 120/208 (3-ph)
Max cont. REbus current (peak) A 20 30
Max cont. grid output current A 32
AC terminals wire size AWG 14 to 6
DC terminals wire size AWG 18 to 6
STOP terminals wire size AWG 28 to 16
Gen Sense/Gen Start wire size AWG 30 to 12
Weight lb (kg) 64 (29)
Thermal management - forced convection
Temperature range ºF (ºC) -4 to 122 (-20 to +50)
Weatherization rating - NEMA 3R
Enclosure Material - powder-coated steel
Ratings
Description Units Min Nominal Max
Maximum Input Voltage (nanogrid) V 420
Range of Input Operating Voltage (nanogrid) V 360 400
Maximum input current (nanogrid) A 20
Maximum input short circuit current (nanogrid) A 30
Maximum input source backfeed current to input
source (nanogrid)
A
30
Output power factor rating (ac) - 1
Operating Voltage range (ac) 2ph V, rms 108 130
Operating Voltage range (ac) 3ph V, rms 106 132
Operating frequency range or single frequency Hz 59.6 60.4
Nominal output voltage (ac) V, rms 120/240 & 208, 3 ph
Normal output frequency (ac) Hz 60
Maximum continuous output current (ac) A, rms 32
Maximum output overcurrent protection A 50
Max output fault current and duration A/ms 50 / 17
Utility interconnection voltage and frequency trip
limits and trip times
Trip voltage and frequency limits
Trip Voltage Accuracy
Trip Time Accuracy - 2% +/-2 cycles
Normal operation temperature range ºF (ºC) -4 (-20) +122 (+50)
Output power temperature derating and maxi-
mum full power operating ambient
ºF (ºC)
-4 (-20)
+122 (+50)
Peak Efficiency % 97.5
CEC Weighted Efficiency % 97
Specifications are subject to change without notice. Refer to the product specification sheet for complete list.
See Generac PWRcell Inverter Installation Manual for more information.
