Generac Power Systems XT8000EFI Owner's Manual

4 Owner’s Manual for Portable Generator
Section 2 General Information and Setup
Figure 2-1. Features and Controls
Generator Components
Figure 2-2. Control Panel
23
14
17
15
18
11
20
16
25
12
21
22
19
13
24
005823
005822
26
28
27
1 Key Switch Ignition
2 120 Volt AC, 20 Amp GFCI Duplex
Receptacle
3 120/240 Volt AC, 30 Amp Locking
Receptacle
4 Circuit Breakers (AC)
5 Idle Control
6 Powerbar™
7 Battery Charger Input
8 Hour Meter
9 Fault Indicator Light
10 Fuse
11 Grounding Lug
12 Spark Arrestor
13 Muffler
14 Fuel Cap
15 Recovery Hose
16 Carbon Canister
17 Air Filter
18 Recoil Starter
19 Handle
20 Fuel Gauge
21 Roll Over Valve
22 Fuel Tank
23 Oil Drain
24 Oil Fill/Dipstick
25 Battery
26 Fuel Pump
27 Ignition Keys
28 Battery Charger
