Page #508 background imageLoading...
Page #508 background image
09
9-55
Engine compartment fuse panel
Fuse Name
Fuse Rating Circuit Protected
ESC3
10A ESP Control Module
ECU3
10A ECM
ECU2
15A ECM
HORN
20A Horn Relay
WIPER1
30A Wiper Power Relay
TCU2
15A P/N Relay, TCM
SENSOR4
10A
Electronic Oil Pump Module, Brake Vacuum Switch, E/R
Junction Block (RLY.1 (Brake Vacuum Relay))
TCU1
20A TCM
WIPER2
10A IBU, ECM
SENSOR1
15A
Rear Sub Junction Block (Fuel Pump Relay),
[D4HB] Rail Pressure Regulating Valve, DieseL Junction
Block (RLY.1 (Fuel Filter Heater Relay))
SENSOR5
20A
[G4KL] Ignition Coil #1/#2/#3/#4
[G6DP] Ignition Coil #1/#2/#3/#4/#5/#6
[D4HB] Electronic Water Pump
MODULE
10A Active Air Flap LH
ACTIVE HOOD
10A Active Hood Lift Control Module
SENSOR1
10A
[D4HB] Glow Relay Unit, Fuel Heater & Water Separator
Sensor
ECU1
20A ECM
SENSOR3
15A
[G4KL] Oxygen Sensor (Up/Down)
[G6DP] Oxygen Sensor #1/#2/#3/#4
[D4HB] Lambda Sensor #1/#2, Electronic VGT Actuator,
Fuel Metering Unit, EGR Cooing Bypass Solenoid
Vlave, PTC Heater, Mid Nox Sensor, PM Sensor,
Rear Nox Sensor
