Maintenance
9-56
Fuse Name
Fuse Rating Circuit Protected
SENSOR2
10A
E/R Junction Block (RLY. 9 - Cooling Fan Relay),
[G4KL] Electronic Thermostat, Oil Control Valve, Purge
Control Solenoid Valve, Recirculation Control
Solenoid Valve
[G6DP] Electronic Thermostat, Oil Pressure Solenoid
Valve, Oil Control Valve #1/#2/#3/#4 (Intake/
Exhaust), Recirculation Control Solenoid Valve,
Purge Control Solenoid Valve, Variable Exhaust
Flap Actuator LH/RH
[D4HB] Oil Pump Solenoid Valve, Air Flow Sensor,
Crankshaft Position Sensor, Front Nox Sensor, Oil
Level Sensor, Stop Lamp Switch
B/ALARM
10A E/R Junction Block (RLY. 2 - Burglar Alarm Horn Relay)
Relay
Type Relay No.
Relay Name
MICRO RLY. 1 Vacuum OIK090033
MICRO RLY. 2 Burglar Alarm Horn Relay
MICRO RLY. 6 Blower Relay
MICRO RLY. 7 Start Relay
MICRO RLY. 8 E-CVVT Relay (G4KL)
MINI RLY. 9 Cooling Fan Relay
To Next Page
