4.3.3 Test Dispense Head
This sub menu allows the engineer to test the operation of the dispense head
mechanism.
1. Press the ↵ (Edit) key to display the test
screen followed by the START/? button on
the drink selection keypad. The dispense
head mechanism will move to its first
dispense position indicated by the screen
opposite.
2. When the head reaches its first dispense position, it will stop and the LCD
screen will show the message Dispense Head Position - Extended.
Press the START/? key a second time to move the head to its second
dispense position. Press the START/? key again to move the head to its
fully extended dispense position.
3. To return the dispense head to its “home”
position and complete the test, press the
START/? key. The dispense head
mechanism will return to its rest position
as indicated by the screen opposite.
4. When the head reaches its “home”
position, it will stop and the LCD screen will show the message Dispense
Head Position - Idle indicating that the test has been completed
successfully. Press the X (Exit) key to return to the main test menu
screen.
4.3.4 Switches & Sensors
This sub menu displays the switches/sensors
that can be tested. For most of the items
displayed the status line at the bottom of the
screen indicates the current state of the
highlighted sensor/switch. In the example
opposite, the status line indicates that the
Waste Bucket Sensor is detecting that the
waste bucket is empty.
N.B. The Brewer Switch 1 menu will only be
displayed on freshbrew models, whilst the
Brewer Switch 2 will only be displayed on
Espresso machines with teapot brewer.
Press the
▲ (up) or ▼ (down) keys to highlight the other switch/sensor inputs
and view their status.
Test Dispe nse Head
Dispe nse Head Position
Press S TOP to Abort
Movi ng
Test Dispe nse Head
Dispe nse Head Position
Press S TART to Begi n
Initi alising
Switches & Sensor s
Empty
Waste Tray Sensor
Cup Turre t Switch
Cup Turre t Sensor
Mug Senso r − Curren t
Mug Senso r − Avera ge
Heater Tank Level
Tank Temp & Heater
Brewer Switc h 1
Brewer Switc h 2
Jug Vend
Free Vend
Technical Manual
29
