4.3.6 Test Vend
This menu allows the engineer to make a test vend in order to verify that the
dispensed vend is acceptable.
1. Highlight Test Vend in the main Test menu
and press the ↵ (Edit) key. The LCD will
display the screen as shown opposite.
2. Make a selection using the drink selection
keypad and press the START/? button. The
machine will drop a cup before dispensing
the selection. If the
SureVend™ system (see page 38) is turned on the
sensors must be activated within 3 seconds of the cup being dispensed.
3. Press the X (Exit) key to return to the main test menu screen.
4.3.7 Grinder Test (B2C Machines)
This sub menu allows the engineer to test for correct operation of the bean
grinder fitted to Espresso machines.
N.B. Remove CoEx® brewer from the machine and place a suitable container
under the grinder outlet to catch any coffee grounds before starting the test
sequence.
1. Highlight Grinder Test in the main Test
menu and press the ↵ (Edit) key. The LCD
will display the screen as shown opposite.
Press button 1 on the drink selection
keypad. The grinder will run for
approximately 4 seconds.
2. Press the X (Exit) key to return to the main test menu screen.
4.3.8 Teapot Assembly Test (B2C Machines)
This sub menu allows the engineer to test for correct operation of the teapot
unit fitted to Espresso machines.
1. Highlight Teapot Assembly Test in the
main Test menu and press the ↵ (Edit)
key. The LCD will display the screen as
shown opposite. Press the START/?
button. The teapot will rotate one full
revolution and the LCD will display the
message Moving.
2. When complete the LCD reverts to the Idle screen. Press the X (Exit)
key to return to the main test menu screen.
Grinder Test
Grinder Number
Press Any Number
1
Test Teapot assembl y
Press S TART (?) to Begin
Idle
Technical Manual
31
