Printer Baud Rate: This allows the engineer to set the correct baud
rate for a serial printer if one is to be used. It is important for this to be
set correctly to ensure successful data transfer.
Serial Flash
This menu only becomes available when a serial flash card (Data Key CMS part
no. EL11301000) is inserted into plug J9A on the control board. It allows the
engineer to upgrade the machine software or backup data. The following
operations are supported:
● View data information
● Delete data
● Load data into the machine
● Save data from the machine
The View, Delete and Load options will only become available when data is
held on the data key. Also, when backup data is added, a description can be
entered to aid retrieval. The following types of data are supported:
● Firmware - The operating system and default factory machine set-up
data
● Default Data - The default factory machine set-up data - eg canister
and button layout, default run times etc.
● Configuration Data - Any machine set-up data that can be changed
by the user
● Configuration and Sales Data - All sales data plus the set-up data
that can be changed by the operator
● Language Data - Not currently used
The data key can hold the following amounts of data - 1 copy of the firmware,
OR 4 copies of default data, and 16 copies of Config data, and 16 copies of
config and sales data. The following example describes how the engineer can
download Config. Data to the data key.
Important! Before inserting the data key, ensure machine is disconnected
from the power supply.
1. Open the door of the machine. Release the catch and open the monetary
door. Remove the control board cover and insert the data key into
connector J9A. Close the door and restore power to the machine.
Technical Manual
58
